SPECIFICATIONS
- Item numberLR23733
- Item description
LED/MINI8/PANEL/5CCT/RD/B
- Size8"
- Shape 6" ROUND BAFFLED
- Dimensions
- Width Ć 8.87"
- Height 1.99"
- Depth 0.69"
- Cutout 8.3"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 1800
- Beam Angle 110Ā°
- CRI 90
ELECTRICAL
- Power (Wattage) 23
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $2.77
- Dimmable TRIAC
- Power Factor 0.9
- Input Current 220mA
- Frequency 60Hz
- Lumen Efficacy 78
- Operating Temp:
- Min -22Ā°
- Max 104Ā°
PACKAGING
- UPC Barcode 644216101313
- Master BarCode 10644216101310
- Master Carton Dimensions:
- Length 18.50"
- Width 9.92"
- Height 9.64"
- Weight 5.345kg
- Case Size 6
