SPECIFICATIONS
- Item numberLR23971
- Item description
LED/CDL6HO/3WO/5CCT/JB/UNV/DD
- Size6"
- Shape 6" ROUND
- Dimensions
- Width Ø 7.36"
- Depth 4.07"
- Cutout Ø5.51"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 1000/1800/2500
- Beam Angle 80°
- CRI 90
ELECTRICAL
- Power (Wattage) 10/17/21
- Input Volts 120-277V
- Rated Lifetime 50000
- Yearly Cost $2.52
- Dimmable TRIAC/0-10V
- Power Factor 0.9
- Frequency 50/60Hz
- Lumen Efficacy 119
- Operating Temp:
- Min -4°
- Max 104°
PACKAGING
- UPC Barcode 793888456747
- Master BarCode 10793888456744
- Master Carton Dimensions:
- Length 15.75"
- Width 7.95"
- Height 10.03"
- Case Size 4
