SPECIFICATIONS
- Item numberLR23972
- Item description
LED/CDL8HO/3WO/5CCT/JB/UNV/DD
- Size8"
- Shape 8" ROUND
- Dimensions
- Width Ø9.45"
- Depth 4.45"
- Cutout Ø7.28"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 1800/2700/3500
- Beam Angle 80°
- CRI 90
ELECTRICAL
- Power (Wattage) 16/24/30
- Input Volts 120-277V
- Rated Lifetime 50000
- Yearly Cost $3.61
- Dimmable TRIAC/0-10V
- Power Factor 0.9
- Frequency 50/60Hz
- Lumen Efficacy 117
- Operating Temp:
- Min -4°
- Max 104°
PACKAGING
- UPC Barcode 793888456846
- Master BarCode 10793888456843
- Master Carton Dimensions:
- Length 20"
- Width 10.03"
- Height 12.40"
- Case Size 4
