SPECIFICATIONS
- Item numberLR23328
- Item description
LED/RDL4/5CCT/SQ/BK2
- Size4"
- Shape 4" SQUARE REGRESSED
- Dimensions
- Length 4.7"
- Width 4.7"
- Depth 3.15"
- Cutout 4"
- Finish BLACK
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 840
- Beam Angle 45º
- CRI 90
ELECTRICAL
- Power (Wattage) 12
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.44
- Dimmable TRIAC
- Power Factor 0.9
- Input Current 0.10A
- Frequency 60Hz
- Lumen Efficacy 70
- Operating Temp:
- Min -4º
- Max 104º
PACKAGING
- UPC Barcode 793888441149
- Master BarCode 10793888441146
- Master Carton Dimensions:
- Length 20.67"
- Width 17.13"
- Height 11.42"
- Weight 11.64kg
- Case Size 24
