SPECIFICATIONS
- Item numberLR23491
- Item descriptionLED/MINI4/FIRE/5CCT/RD/WT/B
- Size4"
- Shape 4" FIRE RATED MINI PANEL
- Dimensions
- Length Ć4.75"
- Height 0.70"
- Finish WHITE
- Cutout Ć3.89"
- Plate LR41002 (#1), LR41006 (#3), LR41010 (#R1), LR41011 (#4)
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 800
- Beam Angle 110Āŗ
- CRI 90
ELECTRICAL
- Power (Wattage) 10
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.20
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 60Hz
- Lumen Efficacy 80
- Operating Temp:
- Min -22Āŗ
- Max 104Āŗ
PACKAGING
- UPC Barcode 793888418448
- Master BarCode 10793888418445
- Master Carton Dimensions:
- Length 12"
- Width 8.46"
- Height 5.82"
- Case Size 6
