SPECIFICATIONS
- Item numberLR41150
- Item description
LEDXSB150/3CCT/3WO/4BA/UNV/D/TLPC/SC /DM/BZ
- Shape SHOEBOX
- Dimensions
- Length 22.46"
- Width 12.39"
- Height 6.26"
- Finish BRONZE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 3000K/4000K/5000K
- Lumen 10,784 (70W)/14,732 (100W)/22,472 (150W) @ TIII/4000K
- Beam Angle T2/T3/T4/T5 - ADJUSTABLE
- CRI 78
ELECTRICAL
- Power (Wattage) 70/100/150
- Input Volts 120-277V
- Rated Lifetime 50000
- Yearly Cost $18.06
- Dimmable 0-10V
- Power Factor 0.9
- Frequency 50/60Hz
- Lumen Efficacy 140/160/150
- Operating Temp:
- Min -40Āŗ
- Max 122Āŗ
PACKAGING
- UPC Barcode 732388959167
- Master BarCode 10732388959164
- Master Carton Dimensions:
- Length 22.36"
- Width 12.40"
- Height 4.72"
- Case Size 1
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. Itās designed to help industry experts formulate and display predicted lighting performance.
