SPECIFICATIONS
- Item numberLR24917
- Item description
TLMD1HO/5CCT/RD/WT
- Size1"
- Shape 1" TRIMLESS
- Dimensions
- Width Ø3.82"
- Depth 3.79"
- Cutout Ø2.36"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/50000K
- Lumen 1000
- Beam Angle 38º
- CRI 80
ELECTRICAL
- Power (Wattage) 12
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.44
- Dimmable TRIAC
- Power Factor 0.9
- Input Current 0.12A
- Frequency 60Hz
- Operating Temp:
- Min -4°
- Max 104°
PACKAGING
- UPC Barcode 732388921461
- Master BarCode 10732388921468
- Master Carton Dimensions:
- Length 21.06"
- Width 11.81"
- Height 11.41"
- Case Size 20
