SPECIFICATIONS
- Item numberLR23751
- Item description
LED/MINI3/PANEL/5CCT/RD2
- Size3"
- Shape 3" ROUND SMOOTH
- Dimensions
- Width Ø 3.75
- Depth 0.75"
- Cutout 3.25"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 540
- Beam Angle 180°
- CRI 80
ELECTRICAL
- Power (Wattage) 8
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $0.96
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 50/60Hz
- Lumen Efficacy 68
- Operating Temp:
- Min -4°
- Max 113°
PACKAGING
- UPC Barcode 644216083411
- Master BarCode 10644216083418
- Master Carton Dimensions:
- Length 19.49''
- Width 13.78''
- Height 9.25''
- Weight 7.00kg
- Case Size 20
