SPECIFICATIONS
- Item numberLR23221
- Item description
LED8W/DL3/GB/5CCT/RD/BK
- Size3"
- Shape 3" GIMBAL
- Dimensions
- Width Ø3.35"
- Height 1.81"
- Cutout 2.75"
- Finish BLACK
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 600
- Beam Angle 40°
- CRI 90
ELECTRICAL
- Power (Wattage) 8
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $0.96
- Dimmable TRIAC
- Power Factor 0.98
- Input Current 80mA
- Frequency 50/60Hz
- Watt Replacement 50
- Lumen Efficacy 75
- Operating Temp:
- Min -40°
- Max 104°
PACKAGING
- UPC Barcode 793888398948
- Master BarCode 10793888398945
- Master Carton Dimensions:
- Length 14.76"
- Width 9.25"
- Height 12.20"
- Weight 16.09lbs
- Case Size 18
FEATURES
CERTIFICATIONS
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. It’s designed to help industry experts formulate and display predicted lighting performance.
