SPECIFICATIONS
- Item numberLR25485
- Item description
LED/ITLMD3/5CCT/SQ/WT/D
- Size3"
- Shape INTERLOCKING TRIMLESS
- Dimensions
- Length 7.08"
- Width 7.08"
- Depth 4.5"
- Cutout 3.93" X 3.93"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/50000K
- Lumen 1000
- Beam Angle 38Āŗ
- CRI 90
ELECTRICAL
- Power (Wattage) 15
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.80
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 60Hz
- Lumen Efficacy 67
- Operating Temp:
- Min -4Ā°
- Max 104Ā°
PACKAGING
- UPC Barcode 793888432048
- Master BarCode 10793888432045
- Master Carton Dimensions:
- Length 22.45"
- Width 15.16"
- Height 16.34"
- Case Size 18
FEATURES
CERTIFICATIONS
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. Itās designed to help industry experts formulate and display predicted lighting performance.
LIFERITE WARRANTY
When you buy from us,
youāre covered by us.
LifeRite is our own, first-party warranty,
available in 2-, 3-, and 5āyear terms,
depending on the exact product.
