LR22832

4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING

LEDRMP4/2WO/5CCT/UDTW/RD/WT/UNV/DD

4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
3D viewer 4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING

LR22832

4" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING

$0.00
/

LEDRMP4/2WO/5CCT/UDTW/RD/WT/UNV/DD

  • CCT 2700K/3000K/3500K/4000K/5000K
  • Lumen 600/900
  • WATT 8/10
  • Size4"

SPECIFICATIONS

  • Item numberLR22832
  • Item description

    LEDRMP4/2WO/5CCT/UDTW/RD/WT/UNV/DD

  • Size4"
  • Shape 4" REGRESSED MINI PANEL
  • Dimensions
    • Width Ø4.73"
    • Depth 1.29"
  • Cutout Ø4.25"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/5000K
  • Lumen 600/900
  • Beam Angle 100°
  • CRI 90

ELECTRICAL

  • Power (Wattage) 8/10
  • Input Volts 120-277V
  • Rated Lifetime 50000
  • Yearly Cost $1.32
  • Dimmable DUAL DIMMING TRIAC/0-10V
  • Lumen Efficacy 81

PACKAGING

  • UPC Barcode 732388946969
  • Master BarCode 10732388946966
  • Master Carton Dimensions:
    • Length 22.87"
    • Width 15.75"
    • Height 13.62"
  • Case Size 24

FEATURES

    90 LIFE HR 50000

CERTIFICATIONS
