LR22836

6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING

LEDRMP6/2WO/5CCT/UDTW/RD/WT/UNV/DD

6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
3D viewer 6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING
6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING

LR22836

6" REGRESSED MINI PANEL DIM TO WARM + 5CCT & 2 WATTAGE SELECTABLE - UNIVERSAL VOLTAGE/DUAL DIMMING

$0.00
/

LEDRMP6/2WO/5CCT/UDTW/RD/WT/UNV/DD

  • CCT 2700K/3000K/3500K/4000K/5000K
  • Lumen 770/1150
  • WATT 12/15
  • Size6"

SPECIFICATIONS

  • Item numberLR22836
  • Item description

    LEDRMP6/2WO/5CCT/UDTW/RD/WT/UNV/DD

  • Size6"
  • Shape 6" REGRESSED MINI PANEL
  • Dimensions
    • Width Ø6.78"
    • Depth 1.52"
  • Cutout Ø6.18"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/5000K
  • Lumen 770/1150
  • Beam Angle 100°
  • CRI 90

ELECTRICAL

  • Power (Wattage) 12/15
  • Input Volts 120-277V
  • Rated Lifetime 50000
  • Yearly Cost $1.80
  • Dimmable DUAL DIMMING TRIAC/0-10V
  • Lumen Efficacy 76

PACKAGING

  • UPC Barcode 732388947065
  • Master BarCode 10732388947062
  • Master Carton Dimensions:
    • Length 17.08"
    • Width 13.54"
    • Height 19.88"
  • Case Size 12

FEATURES

    90 LIFE HR 50000

CERTIFICATIONS

DOCUMENTS
