LR23218

6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE

LED5W/DL6/FGB/5CCT/RD

6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE
6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE
6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE
6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE
6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE
6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE
3D viewer 6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE
6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE
6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE

LR23218

6" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE

$0.00
/

LED5W/DL6/FGB/5CCT/RD

  • CCT 2700K/3000K/3500K/4000K/5000K
  • Lumen 1100
  • WATT 15
  • Size6"

SPECIFICATIONS

  • Item numberLR23218
  • Item description

    LED5W/DL6/FGB/5CCT/RD

  • Size6"
  • Shape FLOATING GIMBAL
  • Dimensions
    • Width Ƙ6.88"
    • Depth 1.51"
  • Cutout Ƙ5.70"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/5000K
  • Lumen 1100
  • Beam Angle 38Ā°
  • CRI 90

ELECTRICAL

  • Power (Wattage) 15
  • Input Volts 120V
  • Rated Lifetime 50000
  • Yearly Cost $1.80
  • Dimmable TRIAC
  • Power Factor 0.9
  • Frequency 60Hz
  • Lumen Efficacy 73
  • Operating Temp:
    • Min -4Ā°
    • Max 104Ā°

PACKAGING

  • UPC Barcode 793888463448
  • Master BarCode 10793888463445
  • Master Carton Dimensions:
    • Length 21.85"
    • Width 14.76"
    • Height 10.43"
  • Case Size 18

FEATURES

    90 LIFE HR 50000
