SPECIFICATIONS
- Item numberLR23222
- Item description
LED8W/DL3/GB/5CCT/SQ
- Size3"
- Shape 3" GIMBAL
- Dimensions
- Length 3.25"
- Width 3.25"
- Height 1.81"
- Cutout 2.75"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 600
- Beam Angle 40Ā°
- CRI 90
ELECTRICAL
- Power (Wattage) 8
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $0.96
- Dimmable TRIAC
- Power Factor 0.98
- Input Current 80mA
- Frequency 50/60Hz
- Watt Replacement 50
- Lumen Efficacy 75
- Operating Temp:
- Min -40Ā°
- Max 104Ā°
PACKAGING
- UPC Barcode 793888399143
- Master BarCode 10793888399140
- Master Carton Dimensions:
- Length 14.76"
- Width 9.25"
- Height 12.20"
- Weight 11.9lbs
- Case Size 18
