SPECIFICATIONS
- Item numberLR23320
- Item description
LED/RDL3/5CCT/RD/WT2
- Size3"
- Shape 3" ROUND REGRESSED
- Dimensions
- Width Ć3.54"
- Depth 2.65"
- Cutout 3"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 840
- Beam Angle 45Āŗ
- CRI 90
ELECTRICAL
- Power (Wattage) 8
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $0.96
- Dimmable TRIAC
- Power Factor 0.9
- Input Current 0.70A
- Frequency 60Hz
- Lumen Efficacy 105
- Operating Temp:
- Min -4Āŗ
- Max 104Āŗ
PACKAGING
- UPC Barcode 793888440449
- Master BarCode 10793888440446
- Master Carton Dimensions:
- Length 17.51"
- Width 15.95"
- Height 9.84"
- Weight 8.64kg
- Case Size 24
