LR23331

3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM

LED9W/DL3/FGB/5CCT/RD

3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM
3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM
3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM
3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM
3D viewer 3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM
3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM
3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM

LR23331

3" RECESSED FLOATING GIMBAL - 5 CCT SELECTABLE ROUND TRIM

$0.00
/

LED9W/DL3/FGB/5CCT/RD

  • CCT 2700K/3000K/3500K/4000K/5000K
  • Lumen 700
  • WATT 9
  • Size3"

SPECIFICATIONS

  • Item numberLR23331
  • Item description

    LED9W/DL3/FGB/5CCT/RD

  • Size3"
  • Shape FLOATING GIMBAL
  • Dimensions
    • Width Ƙ4.33"
    • Depth 1.3"
  • Cutout Ƙ3.54"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/5000K
  • Lumen 700
  • Beam Angle 50Ā°
  • CRI 90

ELECTRICAL

  • Power (Wattage) 9
  • Input Volts 120V
  • Rated Lifetime 50000
  • Yearly Cost $1.08
  • Dimmable TRIAC
  • Power Factor 0.9
  • Frequency 50/60Hz
  • Lumen Efficacy 77
  • Operating Temp:
    • Min -4Ā°
    • Max 104Ā°

PACKAGING

  • UPC Barcode 732388935963
  • Master BarCode 10732388935960
  • Master Carton Dimensions:
    • Length 14.96"
    • Width 13.38"
    • Height 8.66"
  • Case Size 20

FEATURES

    90 LIFE HR 50000
