SPECIFICATIONS
- Item numberLR23480
- Item descriptionLED/MINI4/FIRE/5CCT/RD/WT
- Size4"
- Shape 4" FIRE RATED MINI PANEL
- Dimensions
- Length Ć5"
- Height 1.25"
- Cutout Ć4.25"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 800
- Beam Angle 120Āŗ
- CRI 90
ELECTRICAL
- Power (Wattage) 12
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.44
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 60Hz
- Lumen Efficacy 67
- Operating Temp:
- Min -4Āŗ
- Max 104Āŗ
PACKAGING
- UPC Barcode 793888412743
- Master BarCode 10793888412740
- Master Carton Dimensions:
- Length 16.53"
- Width 11.22"
- Height 9.25"
- Weight 7.58kg
- Case Size 18
FEATURES
CERTIFICATIONS
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. Itās designed to help industry experts formulate and display predicted lighting performance.
