LR23490

3" FIRE RATED STEP BAFFLED CANLESS SPOTLIGHT - 5CCT SELECTABLE

LED/MINI3/FIRE/5CCT/RD/WT/B

LR23490

3" FIRE RATED STEP BAFFLED CANLESS SPOTLIGHT - 5CCT SELECTABLE

$0.00
/

LED/MINI3/FIRE/5CCT/RD/WT/B

  • CCT 2700K/3000K/3500K/4000K/5000K
  • Lumen 550
  • WATT 6.5
  • Size3"

SPECIFICATIONS

  • Item numberLR23490
  • Item description

    LED/MINI3/FIRE/5CCT/RD/WT/B

  • Size3"
  • Shape 3" FIRE RATED MINI PANEL
  • Dimensions
    • Length Ƙ3.54"
    • Height 0.70"
  • Cutout Ƙ3"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/5000K
  • Lumen 550
  • Beam Angle 110Āŗ
  • CRI 90

ELECTRICAL

  • Power (Wattage) 6.5
  • Input Volts 120V
  • Rated Lifetime 50000
  • Yearly Cost $0.78
  • Dimmable TRIAC
  • Power Factor 0.9
  • Frequency 60Hz
  • Lumen Efficacy 85
  • Operating Temp:
    • Min -22Āŗ
    • Max 104Āŗ

PACKAGING

  • UPC Barcode 793888458949
  • Master BarCode 10793888458946
  • Master Carton Dimensions:
    • Length 12"
    • Width 8.46"
    • Height 5.82"
  • Case Size 6

FEATURES

    90 LIFE HR 50000
