SPECIFICATIONS
- Item numberLR23493
- Item descriptionLED/MINI6/FIRE/5CCT/RD/WT/B
- Size6"
- Shape 6" FIRE RATED MINI PANEL
- Dimensions
- Length Ć6.79"
- Height 0.70"
- Cutout Ć5.86"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 1050
- Beam Angle 110Āŗ
- CRI 90
ELECTRICAL
- Power (Wattage) 13
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.56
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 60Hz
- Lumen Efficacy 80
- Operating Temp:
- Min -22Āŗ
- Max 104Āŗ
PACKAGING
- UPC Barcode 793888418547
- Master BarCode 10793888418544
- Master Carton Dimensions:
- Length 16.06"
- Width 8.46"
- Height 7.32"
- Case Size 6
FEATURES
CERTIFICATIONS
