SPECIFICATIONS
- Item numberLR23493
- Item descriptionLED/MINI6/FIRE/5CCT/RD/WT/B
- Size6"
- Shape 6" FIRE RATED MINI PANEL
- Dimensions
- Length Ø6.79"
- Height 0.70"
- Cutout Ø5.86"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 1050
- Beam Angle 110º
- CRI 90
ELECTRICAL
- Power (Wattage) 13
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.56
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 60Hz
- Lumen Efficacy 80
- Operating Temp:
- Min -22º
- Max 104º
PACKAGING
- UPC Barcode 793888418547
- Master BarCode 10793888418544
- Master Carton Dimensions:
- Length 16.06"
- Width 8.46"
- Height 7.32"
- Case Size 6
FEATURES
CERTIFICATIONS
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. It’s designed to help industry experts formulate and display predicted lighting performance.
LIFERITE WARRANTY
When you buy from us,
you’re covered by us.
LifeRite is our own, first-party warranty,
available in 2-, 3-, and 5—year terms,
depending on the exact product.
