LR23496

4" FIRE RATED CANLESS WAFER SPOTLIGHT - 5 CCT SELECTABLE

$0.00
/

LED/MINI4/FIRE/5CCT/RD/WT/2

  • CCT 2700K/3000K/3500K/4000K/5000K
  • Lumen 820
  • WATT 10
  • Size4"

SPECIFICATIONS

  • Item numberLR23496
  • Item description

    LED/MINI4/FIRE/5CCT/RD/WT/2

  • Size4"
  • Shape 4" FIRE RATED MINI PANEL
  • Dimensions
    • Length Ƙ4.75"
    • Height 2.36"
  • Cutout Ƙ3.39"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/5000K
  • Lumen 820
  • Beam Angle 110Āŗ
  • CRI 90

ELECTRICAL

  • Power (Wattage) 10
  • Input Volts 120V
  • Rated Lifetime 50000
  • Yearly Cost $1.20
  • Dimmable TRIAC
  • Power Factor 0.9
  • Frequency 50/60Hz
  • Lumen Efficacy 82
  • Operating Temp:
    • Min -4Āŗ
    • Max 104Āŗ

PACKAGING

  • UPC Barcode 732388936663
  • Master BarCode 10732388936660
  • Master Carton Dimensions:
    • Length 12"
    • Width 8.58"
    • Height 5.82"
  • Case Size 6

FEATURES

    90 LIFE HR 50000
