SPECIFICATIONS
- Item numberLR23759
- Item description
LED/MINI4/PANEL/5CCT/SQ2
- Size4"
- Shape 4" SQUARE SMOOTH
- Dimensions
- Length 5.03"
- Width 5.03"
- Height 1.18"
- Cutout 4.25"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 750
- Beam Angle 180Ā°
- CRI 80
ELECTRICAL
- Power (Wattage) 10
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.2
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 50/60Hz
- Lumen Efficacy 70
- Operating Temp:
- Min -4Ā°
- Max 113Ā°
PACKAGING
- UPC Barcode 644216079612
- Master BarCode 10644216079619
- Master Carton Dimensions:
- Length 18.50''
- Width 12.80''
- Height 11.61''
- Weight 8.62kg
- Case Size 20
