LR23920

3" ECO BACKLIT MINI PANEL CANLESS SPOTLIGHT - 5CCT SELECTABLE HIGH OUTPUT

LED/EMINI3/PANEL/5CCT/HO/RD

LR23920

3" ECO BACKLIT MINI PANEL CANLESS SPOTLIGHT - 5CCT SELECTABLE HIGH OUTPUT

$0.00
/

LED/EMINI3/PANEL/5CCT/HO/RD

  • CCT 2700K/3000K/3500K/4000K/5000K
  • Lumen 660
  • WATT 8
  • Size3"

SPECIFICATIONS

  • Item numberLR23920
  • Item description

    LED/EMINI3/PANEL/5CCT/HO/RD

  • Size3"
  • Shape 3" ROUND SMOOTH
  • Dimensions
    • Width Ø3.86"
    • Depth 1.3"
  • Cutout 3.23"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/5000K
  • Lumen 660
  • Beam Angle 100°
  • CRI 80

ELECTRICAL

  • Power (Wattage) 8
  • Input Volts 120V
  • Rated Lifetime 50000
  • Yearly Cost $0.96
  • Dimmable TRIAC
  • Power Factor 0.9
  • Input Current 0.08A
  • Frequency 60Hz
  • Lumen Efficacy 83
  • Operating Temp:
    • Min -4°
    • Max 104°

PACKAGING

  • UPC Barcode 732388936861
  • Master BarCode 10732388936868
  • Master Carton Dimensions:
    • Length 18.70"
    • Width 12"
    • Height 9.05"
  • Case Size 20

FEATURES

    80 LIFE HR 50000

CERTIFICATIONS

DOCUMENTS
