LR23931
4" MINI PANEL CANLESS SPOTLIGHT - CCT & WATTAGE SELECTABLE DUAL DIMMING/UNIVERSAL VOLTAGE - HIGH OUTPUT
LED/MINI4/PNL/3WO/5CCT/RD/UNV/DD
SPECIFICATIONS
- Item numberLR23931
- Item description
LED/MINI4/PNL/3WO/5CCT/RD/UNV/DD
- Size4"
- Shape 4" MINI PANEL
- Dimensions
- Width Ø5.03"
- Depth 0.44"
- Cutout Ø4.33"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 650/800/1066
- Beam Angle 105°
- CRI 90
ELECTRICAL
- Power (Wattage) 8/10/13
- Input Volts 120-277V
- Rated Lifetime 50000
- Yearly Cost $1.56
- Dimmable TRIAC/0-10V
- Power Factor 0.9
- Frequency 50/60Hz
- Lumen Efficacy 82
- Operating Temp:
- Min -4°
- Max 104°
PACKAGING
- UPC Barcode 793888461048
- Master BarCode 10793888461045
- Master Carton Dimensions:
- Length 21.45"
- Width 15.15"
- Height 11.41"
- Case Size 20
FEATURES
