SPECIFICATIONS
- Item numberLR23948
- Item description
LED/CDL4HO/3WO/3CCT/B/JB
- Size4"
- Shape 4" ROUND
- Dimensions
- Width Ø 5.12"
- Height 3.44"
- Cutout 4.3"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 3000K/4000K/5000K
- Lumen 810/1080/1350
- CRI 80
ELECTRICAL
- Power (Wattage) 9/12/15
- Input Volts 120-277V
- Rated Lifetime 50000
- Yearly Cost $1.8
- Dimmable 0-10V
- Power Factor 0.9
- Frequency 50/60Hz
- Lumen Efficacy 90
- Operating Temp:
- Min -4°
- Max 104°
PACKAGING
- UPC Barcode 644216095711
- Master BarCode 10644216095718
- Master Carton Dimensions:
- Length 20.28''
- Width 15.75''
- Height 13.39''
- Weight 8.00kg
- Case Size 12
FEATURES
CERTIFICATIONS
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. It’s designed to help industry experts formulate and display predicted lighting performance.
LIFERITE WARRANTY
When you buy from us,
you’re covered by us.
LifeRite is our own, first-party warranty,
available in 2-, 3-, and 5—year terms,
depending on the exact product.
