SPECIFICATIONS
- Item numberLR25030
- Item description
LED/DLMD2/5CCT/D/WFL
- Size2"
- Shape 2" INTERCHANGABLE
- Dimensions
- Width Ø2.16" (3.15" w/Trim)
- Depth 1.77" (2.75" w/trim)
- Cutout 2.83"
- Finish BLACK
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 600
- Beam Angle 38°
- CRI 90
ELECTRICAL
- Power (Wattage) 8
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $0.96
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 60Hz
- Lumen Efficacy 75
- Operating Temp:
- Min -4°
- Max 104°
PACKAGING
- UPC Barcode 793888461444
- Master BarCode 10793888461441
- Master Carton Dimensions:
- Length 15.35"
- Width 12.40"
- Height 8.07"
- Case Size 18
