SPECIFICATIONS
- Item numberLR25470
- Item description
LED/ITLMD1/5CCT/SQ/WT/D
- Size1"
- Shape INTERLOCKING TRIMLESS
- Dimensions
- Length 4.25"
- Width 4.25"
- Depth 3.42"
- Cutout 2.44" X 2.44"
- Finish WHITE
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/50000K
- Lumen 500
- Beam Angle 38º
- CRI 90
ELECTRICAL
- Power (Wattage) 7
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $0.84
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 60Hz
- Lumen Efficacy 75
- Operating Temp:
- Min -4°
- Max 104°
PACKAGING
- UPC Barcode 793888431348
- Master BarCode 10793888431345
- Master Carton Dimensions:
- Length 15.94"
- Width 15.94"
- Height 6.89"
- Case Size 18
