LR25480

2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE

LED/ITLMD2/HO/5CCT/SQ/WT/D

2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
3D viewer 2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE
2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE

LR25480

2" INTERLOCKING HIGH OUTPUT TRIMLESS MODULE - 5CCT SELECTABLE

$0.00
/

LED/ITLMD2/HO/5CCT/SQ/WT/D

  • CCT 2700K/3000K/3500K/4000K/50000K
  • Lumen 1000
  • WATT 15
  • Size2"

SPECIFICATIONS

  • Item numberLR25480
  • Item description

    LED/ITLMD2/HO/5CCT/SQ/WT/D

  • Size2"
  • Shape INTERLOCKING TRIMLESS
  • Dimensions
    • Length 5.75"
    • Width 5.75"
    • Depth 4.92"
  • Cutout 3.25" x 3.25"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/50000K
  • Lumen 1000
  • Beam Angle 38Āŗ
  • CRI 90

ELECTRICAL

  • Power (Wattage) 15
  • Input Volts 120V
  • Rated Lifetime 50000
  • Yearly Cost $1.8
  • Dimmable TRIAC
  • Power Factor 0.9
  • Frequency 60Hz
  • Operating Temp:
    • Min -4Ā°
    • Max 104Ā°

PACKAGING

  • UPC Barcode 793888431942
  • Master BarCode 10793888431949
  • Master Carton Dimensions:
    • Length 18.89"
    • Width 12.80"
    • Height 17.52"
    • Weight 12.65kg
  • Case Size 18

FEATURES

    90 LIFE HR 50000

CERTIFICATIONS

DOCUMENTS
