LR40572

120W SEMI CUTOFF WALLPACK – PHOTOCELL SENSOR 3CCT & WATTAGE SELECTABLE

LEDWP120/3WO/3CCT/B/PC/D

LR40572

120W SEMI CUTOFF WALLPACK – PHOTOCELL SENSOR 3CCT & WATTAGE SELECTABLE

$0.00
/

LEDWP120/3WO/3CCT/B/PC/D

  • CCT 3000K/4000K/5000K
  • Lumen 12640/15500/18240
  • WATT 80/100/120
  • Size14.17" X 8.59"

SPECIFICATIONS

  • Item numberLR40572
  • Item description

    LEDWP120/3WO/3CCT/B/PC/D

  • Size14.17" X 8.59"
  • Shape WALLPACK
  • Dimensions
    • Length 14.17"
    • Width 8.59"
    • Depth 6.55"
  • Finish BRONZE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 3000K/4000K/5000K
  • Lumen 12640/15500/18240
  • Beam Angle 93*102°
  • CRI 80

ELECTRICAL

  • Power (Wattage) 80/100/120
  • Input Volts 120-277V
  • Rated Lifetime 50000
  • Yearly Cost $14.45
  • Dimmable 0-10V
  • Power Factor 0.9
  • Input Current 0.6A
  • Frequency 50/60Hz
  • Lumen Efficacy 158/155/152
  • Operating Temp:
    • Min -40º
    • Max 122º

PACKAGING

  • UPC Barcode 732388921362
  • Master BarCode 10732388921369
  • Master Carton Dimensions:
    • Length 16.14"
    • Width 11.42"
    • Height 9.45"
    • Weight 9.92lbs
  • Case Size 1

FEATURES

    80 LIFE HR 50000

CERTIFICATIONS
