SPECIFICATIONS
- Item numberLR23739
- Item description
LED/MINI4/PANEL/5CCT/SQ/B/HO
- Size4"
- Shape BAFFLED SQUARE WAFER
- Dimensions
- Length 5.04"
- Width 5.04"
- Height 1.42
- Cutout 4.33" x 4.33"
- Finish WHITE
- MOL 5.04"
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 950
- Beam Angle 110º
- CRI 80
ELECTRICAL
- Power (Wattage) 12
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $1.44
- Dimmable TRIAC
- Power Factor 0.98
- Frequency 60Hz
- Lumen Efficacy 70
- Operating Temp:
- Min -4°
- Max 113°
PACKAGING
- UPC Barcode 793888392441
- Master BarCode 10793888392448
- Master Carton Dimensions:
- Length 16.14"
- Width 11.96"
- Height 10.82"
- Weight 11.34kg
- Case Size 20
FEATURES
CERTIFICATIONS
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. It’s designed to help industry experts formulate and display predicted lighting performance.
