SPECIFICATIONS
- Item numberLR24990
- Item descriptionLED/DLMD5-6HO/5CCT/D
- Size5-6"
- Shape 5-6" INTERCHANGEABLE
- Dimensions
- Width Ø4"
- Depth 2.55"
- Cutout Ø5.19" w/5" Trim - Ø6.22" w/6"Trim
- Finish BLACK
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 2700K/3000K/3500K/4000K/5000K
- Lumen 1700
- Beam Angle 38º
- CRI 90
ELECTRICAL
- Power (Wattage) 22
- Input Volts 120V
- Rated Lifetime 50000
- Yearly Cost $2.64
- Dimmable TRIAC
- Power Factor 0.9
- Frequency 60Hz
- Lumen Efficacy 77
- Operating Temp:
- Min -4º
- Max 104º
PACKAGING
- UPC Barcode 793888417243
- Master BarCode 10793888417240
- Master Carton Dimensions:
- Length 18.30"
- Width 14.76"
- Height 6.89"
- Case Size 18
