LR23730

3" MINI PANEL ROUND 5CCT BAFFLED CANLESS WAFER SPOTLIGHT

LED/MINI3/PANEL/5CCT/RD/B

3" MINI PANEL ROUND 5CCT BAFFLED CANLESS WAFER SPOTLIGHT
3" MINI PANEL ROUND 5CCT BAFFLED CANLESS WAFER SPOTLIGHT

LR23730

3" MINI PANEL ROUND 5CCT BAFFLED CANLESS WAFER SPOTLIGHT

$0.00
/

LED/MINI3/PANEL/5CCT/RD/B

  • CCT 2700K/3000K/3500K/4000K/5000K
  • Lumen 400
  • WATT 6
  • Size3"

SPECIFICATIONS

  • Item numberLR23730
  • Item description

    LED/MINI3/PANEL/5CCT/RD/B

  • Size3"
  • Shape 3" ROUND BAFFLED
  • Dimensions
    • Width Ø 3.62"
    • Depth 0.69"
  • Cutout 3"
  • Finish WHITE

PHOTOMETRIC

  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 2700K/3000K/3500K/4000K/5000K
  • Lumen 400
  • Beam Angle 110°
  • CRI 90

ELECTRICAL

  • Power (Wattage) 6
  • Input Volts 120V
  • Rated Lifetime 50000
  • Yearly Cost $0.72
  • Dimmable TRIAC
  • Power Factor 0.9
  • Input Current 54mA
  • Frequency 60Hz
  • Lumen Efficacy 66
  • Operating Temp:
    • Min -22°
    • Max 104°

PACKAGING

  • UPC Barcode 644216101016
  • Master BarCode 10644216101013
  • Master Carton Dimensions:
    • Length 8.97"
    • Width 8.26"
    • Height 5.78"
    • Weight 5.02lbs
  • Case Size 6

FEATURES

    90 LIFE HR 50000

CERTIFICATIONS
