SPECIFICATIONS
- Item numberLR42340
- Item description
LEDGS/SM/24/UNV/D/5CCT/916
- Size24"
- Shape GRID SMART
- Dimensions
- Length 23.98"
- Width 0.57"
- Depth 0.63"
- Finish FROSTED WHITE
- MOL 23.98"
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 3000K/3500K/4000K/5000K/6500K
- Lumen 1950
- Beam Angle 120Āŗ
- CRI 80
ELECTRICAL
- Power (Wattage) 15
- Input Volts 100-277V
- Rated Lifetime 50000
- Yearly Cost $1.80
- Dimmable 0-10V
- Power Factor 0.9
- Input Current 0.17A
- Frequency 50/60Hz
- Lumen Efficacy 130
- Operating Temp:
- Min -4Āŗ
- Max 113Āŗ
PACKAGING
- UPC Barcode 732388963461
- Master BarCode 10732388963468
- Master Carton Dimensions:
- Length 25.4"
- Width 7.1"
- Height 10.5"
- Weight 10.7lb
- Case Size 32
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. Itās designed to help industry experts formulate and display predicted lighting performance.
