SPECIFICATIONS
- Item numberLR42345
- Item description
LEDGS/SM/96/UNV/D/5CCT/1516
- Size96"
- Shape GRID SMART
- Dimensions
- Length 95.98"
- Width 0.95"
- Depth 0.75"
- Finish FROSTED WHITE
- MOL 95.98"
PHOTOMETRIC
- Color (Temp) CCT SELECTABLE
- Color (CCT) 3000K/3500K/4000K/5000K/6500K
- Lumen 7800
- Beam Angle 120Āŗ
- CRI 80
ELECTRICAL
- Power (Wattage) 60
- Input Volts 100-277V
- Rated Lifetime 50000
- Yearly Cost $7.22
- Dimmable 0-10V
- Power Factor 0.9
- Input Current 0.67A
- Frequency 50/60Hz
- Lumen Efficacy 130
- Operating Temp:
- Min -4Āŗ
- Max 113Āŗ
PACKAGING
- UPC Barcode 732388963966
- Master BarCode 10732388963963
- Master Carton Dimensions:
- Length 97.5"
- Width 8.7"
- Height 12.1"
- Weight 44.6lb
- Case Size 32
LUXIFLOW
Lighting Layout Software
Our dynamic software tool allows you to estimate the optimum illuminance level, number of luminairies, power density, and luminaire/pole spacing necessary for interior and exterior spaces. Itās designed to help industry experts formulate and display predicted lighting performance.
